MOTORCYCLE - BRAKE DISCS - FMD0249

Choose Code:

FMD0249

REAR

R Version

DIMENSIONS
A Outside Diam. mm 220
B Inside Diam. mm 89
C Thickness mm 5
D Fixing Holes Number 5
E Fixing Holes Diam. mm 10.5
F Fixing Holes Centreline Diam. mm 110



MATERIAL AVAILABILITY
RRFRPRPFRXMXRRS

COMPETITOR XREF
BRAKINGSZ22RID
BRAKINGSZ22RI
EBCMD3060
NEWFRENDF5022 A
NG791
EQUIVALENT OE #
OEM69211 33E00
OEM69211 33E10
OEM Suzuki69211 18G00
OEM Suzuki69211 40F10
Applications
SUZUKI
MAKE MODEL CC START   END FRONT NUM SET SIDE REAR NUM SET SIDE
SUZUKI GSX R 600 1997 > 2003 FMD0125 2 FMD0249
SUZUKI GSX R (Rad.cal) 600 2004 > 2005 FMD0241 2 FMD0249
SUZUKI GSX R 600 2004 > 2005 FMD0241 2 FMD0249
SUZUKI GSX R (Rad.cal) 600 2006 > 2007 FMD0393 2 FMD0249
SUZUKI GSX R 600 2006 > 2007 FMD0393 2 FMD0249
SUZUKI GSX R 600 2008 > 2017 FMD0412 2 FMD0249
SUZUKI SV 650 2003 > 2010 FMD0349 2 FMD0249
SUZUKI SV S 650 2003 > 2009 FMD0349 2 FMD0249
SUZUKI GSX R 750 1996 > 2003 FMD0125 2 FMD0249
SUZUKI GSX R Y 750 2000 > 2003 FMD0125 2 FMD0249
MAKE MODEL CC START   END FRONT NUM SET SIDE REAR NUM SET SIDE
SUZUKI GSX R 750 2004 > 2005 FMD0241 2 FMD0249
SUZUKI GSX R (Rad.cal) 750 2004 > 2005 FMD0241 2 FMD0249
SUZUKI GSX R 750 2006 > 2007 FMD0393 2 FMD0249
SUZUKI GSX R (Rad.cal) 750 2006 > 2007 FMD0393 2 FMD0249
SUZUKI GSX R 750 2008 > 2017 FMD0412 2 FMD0249
SUZUKI GSX R 1000 2001 > 2002 FMD0125 2 FMD0249
SUZUKI GSX R 1000 2003 > 2004 FMD0241 2 FMD0249
SUZUKI GSX R (Rad.cal) 1000 2005 > 2008 FMD0393 2 FMD0249
SUZUKI GSX R 1000 2005 > 2008 FMD0393 2 FMD0249
SUZUKI GSX R 1000 2009 > 2015 FMD0412 2 FMD0249
MAKE MODEL CC START   END FRONT NUM SET SIDE REAR NUM SET SIDE
SUZUKI GSX R ABS 1000 2016 > FMD0412 2 FMD0249
SUZUKI SV 1000 2003 > 2007 FMD0249
SUZUKI SV S 1000 2003 > 2007 FMD0249
SUZUKI TL S 1000 1997 > 2001 FMD0125 2 FMD0249
SUZUKI TL R 1000 1998 > 2003 FMD0125 2 FMD0249
SUZUKI GSX R 1100 1987 > 1988 FMD0249
